Table Size 800*400mm VMC650 4 Axis CNC Milling Machine with Siemens and Fanuc System
VMC650 cnc milling machine 4 axis with siemens and fanuc system
| 650 | unit | parameter |
| Work counter (long * wide) | mm | 800*400 |
| Table load | Kg | 450 |
| X/ Y / Z | mm | 650*400*500 |
| Main shaft end to work table | mm | 120--620 |
| specification | mm | 3*18 |
| Center distance | mm | 125 |
| taper | | BT40 |
| Distance between spindle center and vertical column guide rail | mm | 496 |
| Spindle speed | rpm | 100--8000 |
| Rated power | Kw | 5.5/7.5 |
| Drive system | | Belt drive |
| Positioning accuracy | mm | 0.007 |
| Repeat positioning accuracy | mm | 0.005 |
| Rated power | Nm | 2010/10/10 |
| X/Y/Z is the maximum moving speed | m/min | 24/24/20 |
| X/Y/Z maximum cutting speed | m/min | 10 |
| capacity | put | 20 |
| Machine weight | kg | 4500 |
| External dimensio | mm | 2550*2160*2300 |
| The power requirements | KVA | 380V 15KVA |
VMC650 cnc milling machine 4 axis with siemens and fanuc system consists of main engine, CNC system, electrical control system, automatic lubricating system, cooling system, totally enclosed protective cover, automatic chip removal device (optional) etc.The machine has the X, Y, Z three axis linkage, in a clamping can finish milling, drilling, boring, expanding continuously, hinge, such as the internal and external screw thread processing a variety of rough and finish machining process, is suitable for processing all kinds of high precision, working procedure, shape more complex parts, to provide users with complex parts processing and quick, perfect integration solutions.
The characteristics of VMC 650 cnc milling machine 4 axis with siemens and fanuc system
1. Adopting the world advanced numerical control system, the M60S series are servo-driven, ensuring the stability of the control system is high, the speed is fast, and the surface is smooth.
The advantages of high precision, the ability to make moulds, is the best choice for mold production.
2. All M60S series controllers are marked with RISC64 bit CPU.
3. Coordinate display value conversion can be freely switched (program value display or manual insertion quantity display switching)
4. Standard internal carrier profile function, working position coordinates and central point measurement functions.
5. Buffer correction function extension: can correspond to IC card/computer link B/DNC/MDI mode.
6. Edit the edit mode in the edit screen, and switch to edit or edit the whole page.
7. Graphical display function improvement: can contain the prop path information to fully display the work coordinates and the actual location of the props compensation.
Company specializing in CNC machinery research and development in 20 years, we have good technology, and advanced team, to provide efficient service, for the ball more than 40 countries research and development, production, sales of the company.CNC lathe, CNC milling machine, machining center
Our company has independently developed a series of numerical control lathes for CK0620, CK6130 and CK6132, and has established a large number of special machine tools for many enterprises, whose products are reliable.Price discount, deeply loved by new and old customers.High-quality finished products, perfect pre-sales and after-sales service, is our company's quality purpose, is the pursuit of all employees of our company, is also the guarantee of the majority of users' trust.
Packaging & Shipping
1.Non-fumigation packaging, we use seaworthy plywood.
2. Steel base plate, it is stronger 3-5 times than normal plywood base plate.
3.Water-proof and damp proof, water resistant film wraped all the machine.
4.Fully sheathed case,prevention of collision and keep the goods intact.
Customer visiting
1. Our customers come from more than 40 different countries and promote the most suitable products for different countries to provide the best service;
2 we participated in many exhibitions, the Chinese machinery exhibition, guangzhou commodities fair, through the exhibition to expand overseas market, we invite customers to visit our factory, also can be customized according to customer demand, through our products and services for customers
1. Our customers come from more than 40 different countries and promote the most suitable products for different countries to provide the best service;
2 we participated in many exhibitions, the Chinese machinery exhibition, guangzhou commodities fair, through the exhibition to expand overseas market, we invite customers to visit our factory, also can be customized according to customer demand, through our products and services for customers
Why choose us
1.Our company has 20 years of experience in CNC lathes.Our company produces more than 1000 CNC machine tools per year, more than 40 countries export, and get good evaluation and affirmation.The high quality assurance of our lathe has good rigidity and stability.
2.electrical components from famous brand, provided by the Japanese and Taiwanese brands, its mechanical precision reach or exceed the international standard. Our CNC lathe is durable, safe and reliable, life for more than 10 years.
3. After 20 years of improvement, we have formed a complete production to maintain high quality and control costs. We will provide high quality prices to help you establish advantages in your local market.
4.We have a professional technical service team that provides the best service for you. Overseas services can provide 24-hour online sales and free after-sales service.
